Orange Pi 5 Pro 4GB/8GB/16GB LPDDR5 Rockchip RK3588S 8-Core 64-Bit Single Board Computer with eMMC Socket, WiFi 5/Bluetooth 5.0, Development Board Run Ubuntu/Debian/Android (4GB)

Hardware ParametersSOC: Master ChipRockchip RK3588S (8nm LP process)CPU: 8-core 64-bit processorbig.LITTLE Architecture: 4-core Cortex-A76 and 4-core Cortex-A55, big core cluster is 2.4GHz, and little core cluster is 1.8GHz frequency.GPU: Arm Mali-G610 Built-in 3D GPU Compatible with OpenGL ES1.1/2.0/3.2, OpenCL 2.2 and Vulkan 1.2NPU: Embedded NPU supports INT4/INT8/INT16 mixed operation, with up to 6TOPS computing powerPMU: RK806-1RAM: LPDDR5 496PIN：4GB/8GB/16GB (optional)Memory: eMMC socket: supports eMMC module (optional) SPI Flash (default empty)Note:either eMMC socket or on-board SPI Flash is preferred. MicroSD (TF) slot M.2 M-KEY slot: NVMe SSD or SATA SSDUSB: USB3.1 Gen1 * 1;USB2.0 1；USB HUB:USB2.0 2（TYPE A）+UAB2.02 row of pinsVideo Output: HDMI2.1 up to 8K @60Hz HDMI2.0, up to 4K @60Hz MIPI DSI 4 Lane, up to 4K @60HzCamera:2MIPI 4 LaneAudio: CODEC: ES8388 3.5mm headphone jack audio input/output Input: onboard MIC HDMI 2.1 eARCEthernet: 10/100/1000Mbps Ethernet with PoE+ support (PoE+ HAT required)Wi-Fi+BT Module: Onboard Wi-Fi5+BT 5.0/BLE module: AP6256PCIe M.2 M-KEY Socket: M.2 M-Key slot supports access to NVMe SSD or SATA SSDExpansion Port: Dual-row pin: 2.54mm 40Pin Supports DC 5V and 3.3V power outputs Configurable UART, PWM, I2C, SPI, CAN, GPIO and other functional interfacesButton: 1* MaskROM, 1*RESET, 1 * POWERPower Source: Supports Type-C power supply, 5V @ 5ALED: RGB LED tri-color indicatorFAN: 5V 2PIN 1.25mm socketRTC: 3V 2PIN 1.25mm socketDebugging: Debug serial port UART included in 40PIN expansion portSupported OS: Orangepi OS（Droid）、Orangepi OS（Arch）、Ubuntu、Debian、Android12

• 🍊[LPDDR5 Memory Standard]: Orange Pi 5 Pro uses Rockchip RK3588S 8-Core(4-core A76 and 4-core A55) 64-Bit processor. With 4GB/8GB/16GB LPDDR5, Orange Pi 5 Pro can meet the edge computing needs of most end devices. Up to 2.4GHz main frequency and 8K display processing, it also supports WiFi 5, Bluetooth 5.0 and eMMC module.
• 🍊[WiFi/Bluetooth/Gigabit Ethernet]: Built-in 2.4G/5G dual-band Wi-Fi 5 and Bluetooth 5.0 with BLE support for stronger and more stable signals and easier and faster network transmission. Besides, Orange Pi 5 Pro supports Gigabit Ethernet with PoE, it can be widely used in factory automation, building automation and other scenarios.
• 🍊[Rich Display Ports]: Equipped with M.2 M-Key slot, Orange Pi 5 Pro supports access to NVMe SSD or SATA SSD to increase massive data storage space and meet the needs of fast read/write and high-capacity storage. It offers HDMI output, GPIO ports, USB, 3.5 mm headphone jack, Gigabit LAN port, M.2 M-key slot, MIPI DSI video output which suitable for high-end applications such as VR camera and depth vision.
• 🍊[More Software Support]: Orange Pi 5 Pro can build computer, wireless server, games, music sounds, video and speaker. Additionally, the Orange Pi 5 Pro development board can run Orange Pi OS/Ubuntu/Debian/Linux/Android 12 OS.
